0.19mm Steelgrip PVC Tape Electrical Self Adhesive Insulation

Product Details

Place of Origin: China

Brand Name: CNPETRO

Certification: ISO

Model Number: PVC

Payment & Shipping Terms

Minimum Order Quantity: 500 Rolls

Packaging Details: 360*360*320mm

Delivery Time: 5 work days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 20000 Rolls/ month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                0.19mm pvc tape electrical, Steelgrip pvc tape electrical, 0.19mm steelgrip self adhesive pvc electrical insulation tape


Materials:	PVC	Color:	Black
Length:	30M,10M	Width:	50mm,100mm,150mm
Elongation:	250%	Adhesive:	2.0N/cm
Fuction:	Outer Protection

Materials:	PVC
Color:	Black
Length:	30M,10M
Width:	50mm,100mm,150mm
Elongation:	250%
Adhesive:	2.0N/cm
Fuction:	Outer Protection

Product Description

0.19mm PVC outer wrap tape

Description

PVC outer wrap is designed for petrolatum tapes,mastic surface,

providing outer mechanical protection and insulation from soil.

PVC outer wrap coated one side with a rubber resin pressure sensitive adhesive.

0.19mm Steelgrip PVC Tape Electrical Self Adhesive Insulation 0

Backing	Soft permanently elastic strip
Form	Available in a roll form
Adhesive	High levels of surface tack
Temperature	Performs at a wide range of temperatures
outer	Achieve a complete bond to the inner layer tape

Advantage

Easy application.

Stable and reliable.

Good comformability.

Non-hardening in cold weather

Good impact resistance

0.19mm Steelgrip PVC Tape Electrical Self Adhesive Insulation 2

Application

After Applying petrolatum tapes. Then, by hand application, wrap the PVC tape ,overlap 55%.

Apply enough tension . PVC Wrap Protection Tape can be applied as outer wrapping tape for visco-elastic tape, Petrolatum tape, Bitumen tape and so on according to different standards.

0.19mm Steelgrip PVC Tape Electrical Self Adhesive Insulation 3

Technical property

Color	Black or Yellow
Thickness	0.2 mm --
Tensile Strength	≥ 15 MPa
Adhesion (To Self)	2.0 N/CM
Adhesion (To Steel)	2.0 N/CM
Elongation at Break	≥250%
Breakdown Voltage (double layer)	≥20KV
Application Temperature	-5 to +55oC
Service Temperature	-50 to +90oC
Roll Length	30 m
Roll Width	50,100,150,200mm

Our vinyl Pipe Wrap Tape is the best non-conducting moisture-proof tape on the market. It protects overhead, exposed, buried or submerged piping against the corrosive action of saltwater, alkalis, and acids from plants and soil. Buried pipes are also protected against galvanic corrosion.
