Flanges, Valves, And Fittings Anti Corrosion Protection Petrolatum Tape

Product Details

Place of Origin: TIANJIN,CHINA

Brand Name: PETROTAPE

Certification: ISO9001,ISO 14001,SGS

Payment & Shipping Terms

Minimum Order Quantity: 20 boxes

Packaging Details: Release film+box+pallet

Delivery Time: 7-14 working days

Payment Terms: T/T, Western Union

Supply Ability: 3000 rolls each day

Get Best Price
Product Details
Highlight:

Anti Corrosion Protection Petrolatum Tape

Specification:
Similar As PETRO Corrosion Protection Petrolatum PETRO Tape
Usage:
Pipe Anticorrosion,Construction,WRAPPING PIPELINES
Other Name:
Grease Tape Petrowrap
International Standard:
AWWAC 217
Color:
Yellow Brown
Specification:
Similar As PETRO Corrosion Protection Petrolatum PETRO Tape
Usage:
Pipe Anticorrosion,Construction,WRAPPING PIPELINES
Other Name:
Grease Tape Petrowrap
International Standard:
AWWAC 217
Color:
Yellow Brown
Product Description

How to Apply  Anti Corrosion Protection Petrolatum Tape?
Clean the surface to remove loose debris, rust, or grease.
Apply a thin layer of petrolatum primer (if required) for better adhesion.
Wrap the tape with a 55% overlap, ensuring complete coverage of the surface.
Smooth out the tape to eliminate air pockets or folds.
Petrolatum anti-corrosion tape is a cost-effective and reliable solution for protecting metal assets in various environments, offering long-term durability and maintenance-free performance.


Application filed:
Pipelines:
Used to wrap above-ground and buried pipelines to protect them from corrosion.
Flanges and Valves:
Protects irregular or hard-to-coat surfaces like flanges, valves, and joints.
Marine Equipment:
Ideal for metal parts exposed to saline environments, such as docks and offshore platforms.
Storage Tanks:
Used on tank bases and other areas prone to corrosion due to water pooling.
Advantages:
Long-lasting protection against corrosion.
Simple and quick installation without the need for specialized tools.
No curing time or drying period required.
Can be used in a wide range of temperatures.
Environmentally safe and non-toxic.

Technical Properties of Petrolatum tape



ParticularsPropertiesTechnical Standard

Thickness
Weight
Tensile Strength
Elongation at Break
Dielectric Rigidity (55% overlap)
Resistance to Acids (10%Hcl)
Resistance Alkalies (10%NaOH)
Resistance Salts (20% Nacl)
Resistance to Cathodic Dis-bonding
Application Temperature
Service Temperature
Dropping Point
Length/Roll
Width/Roll


≥1.15 mm avg.
≥ 1.44 kg/m2 avg.
≥ 200 N/ 50 mm
10% avg.
≥ 16 kV
Excellent
Excellent
Excellent
< 500 mm2
-5 to +55 Deg C
-50 to +75 Deg C
85 Deg C
10 meters
50/75/100/150
/200/300 mm



ASTM D1000

ASTM G8

ANSI/AWWA C 209-00;

SY/T 0414-2007

Tape Widthm2/RollRolls/Carton
50mm0.5036
75mm0.7524
100mm1.018
150mm1.512
200mm2.08
300mm3.06


Raw Materials for anti corrosion protection petrolatum tape:
The tape is made from a fabric or synthetic carrier that is impregnated with a neutral petrolatum-based compound. It often includes inert fillers and corrosion inhibitors for enhanced performance.
Moisture Resistance:
It is impermeable to water and oxygen, ensuring excellent protection against rust, corrosion, and degradation caused by environmental exposure.
Self-Adhesive Properties:
The tape has a tacky surface that adheres easily to the substrate without requiring heat or special tools.
Non-Hardening Compound:
The petrolatum compound remains soft and flexible over time, allowing it to conform to irregular surfaces and maintain its protective barrier.
UV Resistance:
Some variants are resistant to ultraviolet (UV) light, making them suitable for outdoor applications.
Ease of Application:
The tape can be applied by hand with minimal surface preparation, requiring only the removal of loose rust, dirt, or grease from the substrate.
